AGX Series
LED Indoor Commercial Grow Light
The AGX™ Series is a full-cycle top-lighting solution for indoor, commercial cultivation, with variable light intensities for use with various stages of cultivation.
APPLICATION
Indoor commercial cultivation.
FEATURES and BENEFITS
- High Intensity (PPF)
- Adjustable Output
- High Efficacy
- Optimized Spectrum, Full Spectrum
- Full Cycle
- Increased Uniformity
- Maximum Yield
Construction
Slim profile, foldable hinged design. Precision-formed extruded aluminum LED module bars. Easy to install driver bracket.
Electrical
Grow light utilizes high efficacy system to run at cool temperatures for reliability. Universal voltage 120- 277V electronic driver with 0-10V dimming and built-in adjustable output. Comes equipped with an 8’ cord with 240V NEMA 6-15P plug.
Installation and Mounting
Optical System
Optimized spectrum for full-cycle, indoor commercial cultivation. High reflectivity material used on modules. Enhanced uniformity and light distribution.
Certifications
ETL Listed, Conforms to UL 8800.
Warranty
5-year Limited Warranty. See warranty documentation for more information.
AGX Line Drawing
| Model No. | Input Power | PPF (Nominal) | PPE (Nominal) |
|---|---|---|---|
| AGX-6L-320-850-IFC | 320W | 850 μmol/s | 2.66 μmol/J |
| AGX-6L-630-1700-IFC | 630W | 1700 μmol/s | 2.70 μmol/J |
| AGX-6L-630X-1900-IFC | 630W | 1900 μmol/s | 3.02 μmol/J |
