SCB Series
LED High Bay
The Aleo SCB™ Series Slim-Profile Circular High Bay delivers industry-leading performance with a durable, heavy-duty construction. Superior performance, ultra high-efficacy and premium quality provides a robust solution for high ceiling applications, especially warehouse spaces. Delivering high output, quality light and low energy consumption can improve warehouse safety and productivity, lower maintenance cost, and reducing operating costs.
APPLICATION
Provides high output illumination for various commercial industrial applications with high ceilings: warehouse, manufacturing, gymnasiums, cold-storage, wash-down area.
FEATURES AND BENEFITS
- Attractive ROI
- Slim profile for easy transportation and installation
- Ideal for use with sensor and advanced controls
- Long life, reduced maintenance
- Wet-Location, IP66 Rated
- Lower energy costs
- High lumen output
- DLC Premium
- 7-year limited warranty
Construction
Rugged, die-cast housing with advanced thermal management system ensures reliability and durability. Weather-proof, gasketed driver compartment protects electronics against environmental elements. IP66, wet location.
Electrical
Luminaire utilizes high-efficacy LED packages maintained at cool temperatures for long life, high efficacy. Reliable driver features continuous dimming. Universal voltage (120-277V) for convenient installation.Comes equipped standard with 6′ black SJTOW cord.
Installation & Mounting
Single point mount for hook, pendant, or stem mounting.
Controls & Dimming
Continuous dimming (0-10V) comes standard. Suitable for use with dimmers, sensors, daylight harvesting and other control strategies to achieve deeper energy-savings and code compliance.
Optical System
Diffuser lens reduces glare and improves occupant working conditions while maintaining high efficiency emission.
Certifications
UL Listed. Wet location rated. All components have UL certification. UL Class 2. Driver: SCP, OTP, OVP protection, FCC Part 15 Class B, UL8750 Class 2. DLC Premium.
Warranty
7-year Limited Warranty. See warranty documentation for more information.
Specification Sheet
Installation Guide
IES Files
Model No. | Nom. Wattage | Lumens |
---|---|---|
SCB-13L/xxK G3 ECO | 97 | 14096 |
SCB-19L/xxK G3 ECO | 146 | 20513 |
SCB-25L/xxK G3 ECO | 198 | 28580 |
SCB-30L/xxK G3 ECO | 234 | 33684 |
