UXB Series

Circular LED High Bay

The Aleo UXB™ Series, Circular High Bay, combines efficiency, robust construction, and utility to deliver a competitive and high-performance high bay solution for single-point mounting applications. The wet location / IP-rated luminaire provides a versatile solution for high mounting facilities. Delivering high output, quality light and low energy consumption, the UXB improves warehouse safety and productivity, lowers maintenance cost, and reduces operating costs.


Provides high output illumination for various commercial industrial applications with high ceilings: warehouse, manufacturing, gymnasiums, cold-storage


  • Attractive ROI
  • Single-point mounting
  • Long life, reduced maintenance
  • Wet-Location, IP66 Rated
  • Lower energy costs
  • High lumen output
  • DLC Premium
  • 7-year limited warranty

Rugged, die-cast housing with advanced thermal management system ensures reliability and durability. Integrated, enclosed water-proof driver protects against environmental elements. IP66, Wet Location Rated. White Finish.

Luminaire utilizes high-efficacy LED packages maintained at cool temperatures for long life, high efficacy. Reliable driver features continuous dimming. Universal voltage (120-277V) for convenient installation. Comes equipped standard with 6’ white SO cord.

Single-point hook mount (hook with screw included).

Continuous dimming (1-10V) comes standard. Suitable for use with dimmers, sensors, daylight harvesting and other control strategies to achieve deeper energy savings and code compliance.

Glass lens provides protection and high efficiency transmission of light. Frosted PC or Aluminum dome reflector accessories available (sold separately) for reduced glare and controlled optics.

UL Listed. Wet location rated.

7-year Limited Warranty. See warranty documentation for more information.

Model No. Nom. Wattage Lumens
UXB-100/50K G3 ECO 103 15422
UXB-150/50K G3 ECO 153 22,822
UXB-200/50K G3 ECO 189.5 27,884
Model No. Description
-PCR70 Frosted Polycarbonate Dome lens
-ALR90 Diffuse Aluminum Reflector
-OSDL/IR Multi-Level Occupancy Sensor with wireless configuration
