LSR UX Series

LED Linear Strip Retrofit Kit

The Aleo LSR™ UX Series Linear Retrofit Kit delivers industry-leading performance with deep energy savings and continuous dimming. Easy and quick installation reduces labor cost and optimizes ROI. The retrofit kit eliminates the need to replace existing luminaire housing, which reduces install time and disposal/ removal costs. The LSR™ UX kit transforms utility strips into high-efficiency, architectural luminaires.

APPLICATION

Excellent for general utilty applications to retrofit existing utility strip/channels. Parking garage, warehouse, offices, restrooms, storage units, stairwell.

FEATURES AND BENEFITS

Quick and Easy Installation
Visually pleasing, architectural design
Continuous dimming for further demand reduction
Compatible with advanced sensor/control integration
Long life, reduced maintenance
7-year limited warranty
UL and DLC Listed

Construction

Integral LED gear tray and reflector with driver on board allows for easy installation and handling. Luminaire features matte white durable finish. Diffuser requires no additional frame or fastener for easy installation.

Optical System

Reflector systems features highly reflective coating and delivers balanced, comfortable illuminance for productive spaces. Diffuser lens reduces glare and improves occupant comfort while maintaining high efficiency emission.

Certifications

UL Classified. All components have UL certification. UL Class 2. Driver: SCP, OTP, OVP protection, FCC Part 15 Class B, UL8750 Class 2. DLC Listed.

Warranty

7-year Limited Warranty. See warranty documentation for more information.

Electrical

Luminaire utilizes high-efficacy LED packages maintained at cool temperatures for long life, high efficacy. Reliable driver features continuous dimming. Universal voltage (120-277V) for convenient installation. Comes equipped with luminaire quick-disconnect.

Installation & Mounting

Features universal mounting bracket to fit strips with 4-1/2” to 5-1/2” width. Includes safety cables for security and wiring. Installs on existing strip housing.

Controls & Dimming

Continuous dimming (0-10V) comes standard. Suitable for use with dimmers, sensors, daylight harvesting and other control strategies to achieve deeper energy savings and code compliance.

Field-Adjustable CCT

Increased versatility and reduced inventory burden. Color Temp. can be adjusted in the field by selecting (3) different CCTs via switch on driver.

4' Line Drawing

8' Line Drawing

Specification Sheet

LSR UX Spec Sheet

Installation Guide

LSR UX Installation Guide

IES Files

LSR UX IES Files (ZIP)

Form Factor	Model No.	Nom. Wattage	3500K Lumens	4000K Lumens	5000K Lumens
4′	LSR-4UXL-30/8CT XE G4	18	2683.5	2977.6	2720.2
		25	3499.2	3890.7	3548.2
		30	4191.1	4646.6	4251.8
8′	LSR-8UXH-65/8CT XE G4	38	5613.6	6237.3	5687
		54	7969.8	8831.4	8077.5
		65	9036	10040	9161.5

Model No.	Description
-EM700	Emergency battery backup, 700 lm
-EM1400	Emergency battery backup, 1400 lm
-EM2000	Emergency battery backup, 2000 lm
-OSDL/HF/IR	Multi-Level High Frequency Occupancy Sensor
