LCP UX Series
LED Square Canopy Luminaire – Field Adjustable
The Aleo LCP Series, LED Square Canopy Luminaire combines energy-efficiency, low-glare optics, and simple slim profile aesthetics to deliver enhanced performance to a range of surface-mount and recessed lighting applications. Mounting plate allows for quick and easy installation. Weather-proof compartment to withstand challenging environments. Perfect for covering existing square recessed openings.
APPLICATION
Covered walkways, drive-thrus, semi-covered outdoor aisles, corridors, building canopies, large stairwells. Covers recessed openings for surface mount application. Perfect for school campuses. Deep energy-savings when replacing both HID and CFL.
FEATURES and BENEFITS
- Aggressive Energy Savings
- Improved aesthetics and light levels
- Replaces existing CFL and HID
- Seamlessly covers existing square recessed openings (12″x12″)
- Multi-level sensor available
- Simple and Clean construction and design
- Easy and Quick Installation
- Damp-Location
- DLC QPL
- 7-year Limited Warranty
Construction
Simple, white finish powder-coated housing with advanced thermal management system ensures reliability and durability.
Electrical
Luminaire utilizes high-efficacy LED packages maintained at cool temperatures for long life, high efficacy. Reliable driver features universal voltage (120-277V) for convenient installation.
Field-Adjustable CCT / Wattage
Increased versatility and reduced inventory burden. Wattage and Color Temp. can be adjusted in the field by selecting (3) different wattages and (3) different CCTs via switch in driver box.
Installation and Mounting
Optical System
Prismatic, square drop lens comes standard. Lens system improves safety and security by delivering high-efficiency illumination with low glare, comfortable illumination.
Certifications
ETL Listed. All components have safety certification. DLC QPL listed
Warranty
7-year Limited Warranty. See warranty documentation for more information.
LCP Line Drawing
| Model No. | Nom. Wattage | 3500K Lumens | 4000K Lumens | 5000K Lumens |
|---|---|---|---|---|
| LCP-20UX/CT (PSMK) | 12W | 1584 | 1632 | 1596 |
| 15W | 1980 | 2040 | 1995 | |
| 20W | 2340 | 2412 | 2358 | |
| LCP-55UX/CT (PSMK) | 33W | 4290 | 4488 | 4422 |
| 43W | 5375 | 5676 | 5590 | |
| 53W | 6413 | 6837 | 6731 |
| Model No. | Description |
|---|---|
| OSDL/HF | Multi-Level High Frequency Occupancy Sensor |
| LCP-PSMK-HOUSING | Back housing enclosure accessory for surface/pendent mount |
