Volumetric LED Troffer - Center Diffuser
The Aleo LT-CD™ Series Volumetric LED Troffer delivers industry-leading performance with deep energy savings and continuous dimming. The precision-formed diffuser produces comfortable and pleasant illumination, enhancing productive spaces in various applications.
Provides architectural aesthetics for retail, schools, offices, healthcare, and other various commercial applications.
FEATURES AND BENEFITS
- Visually pleasing, architectural design
- Continuous dimming for further demand reduction
- Long life, reduced maintenance
- 7-year Limited warranty
- UL and DLC Premium
Simple construction with minimal parts allows for easy handling and installation. Low profile design optimizes shipping, storage, and handling. Luminaire features matte white durable finish. Integral T-Bar clips built into luminaire. Diffuser requires no additional frame or fastener for easy installation.
Luminaire utilizes high-efficacy LED packages maintained at cool temperatures for long life, high efficacy. Reliable driver features continuous dimming. Universal voltage (120-277V) for convenient installation.Comes equipped with luminaire quick-disconnect.
Installation & Mounting
Installs in most standard T-Bar ceiling grid systems. Flange kit available for hard-lid/drywall appplications. Surface-mount kit accessory available.
Controls & Dimming
Continuous dimming (0-10V) comes standard. Suitable for use with dimmers, sensors, daylight harvesting and other control strategies to achieve deeper energy-savings and code compliance.
Reflector systems features highly reflective coating and delivers balanced, comfortable illuminance for productive spaces. Diffuser lens reduces glare and improves occupant comfort while maintaining high efficiency emission.
UL Listed. All components have UL certification. UL Class 2. Driver: SCP, OTP, OVP protection, FCC Part 15 Class B, UL8750 Class 2. DLC Premium.
7-year Limited Warranty. See warranty documentation for more information.
1X4 Line Drawing
2X2 Line Drawing
2X4 Line Drawing
|Form Factor||Model No.||Nom. Wattage||Lumens|
|1’x4′||LT-CD-14HE-26/840 XE G3||26W||3250|
|2’x2′||LT-CD-22LE-18/840 XE G3||18W||2340|
|2’x2′||LT-CD-22HE-26/840 XE G3||26W||3250|
|2’x4′||LT-CD-24VLE-25/840 XE G3||25W||3500|
|2’x4′||LT-CD-24LE-34/840 XE G3||34W||4590|
|2’x4′||LT-CD-24HE-48/840 XE G3||46W||5796|
|-EM700||Emergency battery backup, 700 lm|
|-EM1400||Emergency battery backup, 1400 lm|
